UL STANDARD
RMC (RIGID METAL CONDUIT)
RMC (RIGID METAL CONDUIT)
Barton RMC is a thick-walled, highly corrosion-resistant, high-strength, threaded ductile steel conduit, designed for heavy duty electrical installations.
Barton RMC conduit is hot dip galvanised after production to ensure maximum protection.
Barton RMC conduit offers excellent resistance to extreme temperatures and corrosive environments.
It has NPT threaded fittings.
It has a coating of zinc on both outside and inside surfaces.
It is non-combustible and can be used indoors, outdoors, underground, concealed or in exposed areas.
Sizes: Nominal trade sizes are from ½” to 6”
Length: RMC conduit is produced in 3.05m (10 ft) traditional standard lengths including coupler.
Features:
- High strength, thick-walled threaded ductile steel conduit.
- Manufactured from galvanised high grade steel.
- Supplied in 3.05m (10 ft) lengths with coupler/connectors.
- American National Standard Institute ANSI C80.3.
- Underwriters Laboratory UL6.
- RMC - Rigid Metal Conduit.
- Excellent resistance to extreme temperatures and environments.
- Does not burn or produce harmful gases.
- Smooth interior for easy wire pulling.
- Connected using EMT/RMC fittings.
RMC (Rigid Metal Conduit)
| BARTON Intermediate Metal Conduit (Dimensions) | |||||||
|---|---|---|---|---|---|---|---|
|
Nominal Trade Size |
Part Number |
Length |
Nominal Outside Diameter |
Nominal Wall Thickness |
|||
|
Inch |
MM |
Inch |
MM |
Inch |
MM |
||
|
1/2 |
16 |
BRMC050 |
3.05m (10 ft) |
0.810 |
21.3
|
0.104
|
2.6 |
|
3/4 |
21 |
BRMC075 |
1.024 |
26.7 |
0.107 |
2.7 |
|
|
1 |
27 |
BRMC100 |
1.285 |
33.4 |
0.126 |
3.2 |
|
|
11/4 |
35 |
BRMC125 |
1.630 |
42.2 |
0.133 |
3.4 |
|
|
11/2 |
41 |
BRMC150 |
1.875 |
48.3 |
0.138 |
3.5 |
|
|
2 |
53 |
BRMC200 |
2.352 |
60.3 |
0.146 |
3.7 |
|
|
21/2 |
63 |
BRMC150 |
2.847 |
73.0 |
0.193 |
4.9 |
|
|
3 |
78 |
BRMC300 |
3.466 |
88.9 |
0.205 |
5.2 |
|
|
31/2 |
91 |
BRMC350 |
3.961 |
101.6 |
0.215 |
5.5 |
|
|
4 |
103 |
BRMC400 |
4.456 |
114.3 |
0.225 |
5.7 |
|
|
5 |
129 |
BRMC500 |
5.563 |
141.3 |
0.245 |
6.2 |
|
|
6 |
155 |
BRMC600 |
6.625 |
168.3 |
0.266 |
6.8 |
|
Large diameters are available on request.
