Rigid GI conduit Fittings and Accessories
Rigid GI conduit Fittings and Accessories
A comprehensive range of Barton fittings and accessories has been designed specifically for use with Barton rigid and flexible steel conduit.
Barton conduit fittings and accessories are available to suit 20, 25 and 32mm, 1½” and 2” diameters of steel conduit. All fittings conform to BS 4568, BSEN 50086 and BS EN IEC 61386.
Small and large circular conduit boxes are manufactured from malleable iron and hot dipped galvanised after manufacture with a tapped hole in the base for an earthing screw. The boxes are supplied without covers or fixing screws unless ordered.
The Barton range includes malleable, steel, brass, zinc, copper and neoprene fittings.
BOXES - CIRCULAR, SMALL
- Terminal No. M181
- Through No. M182
- Angle No. M183
- Tee No. M184
- Intersection No. M185
- Back Outlet No. M186
- Terminal and Back Outlet No. M187
- Through and Back Outlet No. M188
- Angle and Back Outlet No. M189
- Tee and Back Outlet No. M190
- Tangent Through No. M192
- Tangent Angle No. M193
- Tangent Tee No. M194
- Branch Two Way (U) No. M195
- Intersection and Back Outlet No. M191
- Branch Three Way (Y) No. M196
- Twin Through Way (H) No. M197
- Branch Two Way (U) and Back Outlet Box No. M198
- Branch Three Way (Y) and Back Outlet Box No. M199
- Twin Through Way (H) and Back Outlet Box No. M200
BOXES - CIRCULAR, LARGE
- Terminal No. M211
- Through No. M212
- Angle No. M213
- Tee No. M214
- Intersection No. M215
- Back Outlet No. M216
- Terminal and Back Outlet No. M217
- Through and Back Outlet No. M218
- Angle and Back Outlet No. M219
- Tee and Back Outlet No. M220
- Tangent Angle No. M222
- Tangent Tee No. M223
- Twin Through Way (U) No. M225
- Intersection and Back Outlet No. M221
- Branch Three Way (Y) M226
- Twin Through Way (H) No. M227
BOXES - CIRCULAR, SMALL SPECIAL DEEP
- Terminal No. M231
- Through No. M232
- Angle No. M233
- Tee No. M234
- Tee No. Intersection No. M235
BOXES - CIRCULAR, SMALL EXTENSION PATTERN
- Terminal No. M241
- Through No. M242
- Angle No. M243
- Tee No. M244
- Intersection No. M245
BOXES - CEILING ROSE
- Shallow No. M361
BOXES - LOOPING IN
- Medium, Steel No. R274
- Medium, Malleable iron No. M272
ADAPTORS
- Imperial to Metric Adaptor No. R114
- Metric to Imperial Adaptor No. R115
COVERS - CIRCULAR SMALL
- Cover, Loose, No Screws. No. RC281
- Cover, Loose, No Screws. No. R281
- Cover, Overlapping, Loose, No Screws No. R280
- Cover, Heavy, Loose, No Screws No. R282
- Cover, Heavy, Loose, No Screws No. M283
- Cover, Female Dome, No. M288
- Cover, Female Dome, No. R289
- Cover, Ball and Socket, Earthed No. M286
- Cover, Hook Dome, Combined No. R287
- Cover, Ball and Socket Earthed No. R290
COVERS - CIRCULAR LARGE
- Cover, Light, Loose, No Screws No. R381
COUPLINGS
- Coupling, Solid No. R101
- Expansion Coupling, Solid No. R104
- Coupling, Inspection No. M103
- Coupling, Earthing No. M105/R105
- Nipple, Normal No. F107
- Nipple, 300mm Long No. F109
- Coupling, Flanged, No. M110/M111
ELBOWS
- Elbow, Solid No. M121
- Elbow, Channel Inspection, No. M123
BENDS
- Bends, Normal, Internal Thread No. R141
- Bend, Inspection No. M145
WASHERS
- Lead No. F112 , Neoprene No. F113
- Serrated No. F116
TEES
- Tee, Solid No. M131
- Tee, Channel Inspection, No. M133
RINGS
- Ring, Extension No. M294/R294
- Clip, Earthing No. F506
BUSHES
- Bush, Short Male No. F531
- Bush, Long Male No. F532
- Bush, Female No. F534
PLUGS AND GLANDS
- Plug, Hexagon Head, No. M527
- Plug, Slotted Head, No. F535
- Gland for T.R.S. or similar cable No. F538
REDUCERS
- Reducer No. M471
LOCKNUTS
- Locknut, Hexagon No. R507
- Locknut, Hexagon Heavy No. R509
- Locknut, Circular, Milled Edge No. F505
SADDLES
- Saddle, Hospital No. M362
- Saddle, Distance No. M363
- Saddle, Spacer Bar, One Way No. R431
- Clip (Half Saddle) No. F441
- Saddle, 1 Way (Single) No. R451
- Crampet, Steel No. F461
SCREWS
- Brass, M4 Pan Head No. F645
- Screw - Steel, Bright Zinc Plated. M4 Pan Head No. F645
- Brass. M4 Earth Terminal Studs No. F657
GASKETS
- Rubber/Neoprene Gasket for Coupling Inspection No. F401
- Rubber/Neoprene Gasket for Elbow, Channel Inspection No. F402
- Rubber/Neoprene Gasket for Box, Small Circular No. F409
- Rubber/Neoprene Gasket for Adaptable boxes No. F415
- Rubber/Neoprene Gasket for Bend, Inspection No. F408
- Rubber/Neoprene Gasket for Tee, Channel Inspection No. F405
- Rubber/Neoprene Gasket for Box, Large Circular No. F410
